Producer information
Company:
Jinan Tianchen Deca Machine Co., Ltd. |
| |
Address:
3/F, Baoshui Zhanmao Building, No.5 Huaxianchang Road, Jinan, Shandong, China (Mainland) Zip: 250100 |
| |
Phone:
+86-531-88161887 +88024026 +8612126 |
|
CNC Corner Cleaning Machine SQJC-CNC-120
Features:1) High efficiency,For profile welding seam cleaning2) High processing precision due to size error compensation function3) Imported servo-drive system, computer control system, solenoid valve,air source disposer and so on, ensured reliable performance and long using life4) Can store many programs for various profile processing5) Can clean multi-shaped welding seams6) Imported servo-drive system, high reliability7) Can clean outside vertical surface, up/bottom welding seam, internalbevel section, seam in the track of the sliding profile, rubber seamgroove part and so on8) Increased window air tightnessSpecifications:1) Air pressure: 0.6 ~ 0.8Mpa2) Air consumption: 150L/min3) Input voltage: 3N ~ 50Hz, 380/220V4) Input power: 5kW5) Profile height: 30 ~ 120mm6) Profile width: 20 ~ 120mm7) Overall dimensions: 2160 x 2100 x 2250mm8) Weight: 1200kg9) Milling cutter revolution: 2800rpmInner packing:Plastic cover, nylon coverOuter packing:Wooden caseCarton dimensions (L x W x H): 2450 x 1500 x 2450mmN.W.: 1,200kgG.W.: 1,400kg
