Double Miter Saw
Product Name: Double Miter SawModel Number: LJZ2C-450 x 5000Place of Origin: ChinaFeatures: 1) Automatic 45 - 90 degrees alternative cutting2) One-time four pieces of profile cutting available (height of the profile should be less than 60mm)3) Machine guide and head feeding adopted linear bearing system4) Automatic machine head brake5) Reasonable structure and high processing precision6) Digital display the profile cutting length and quantity7) With head fine adjusting deviceSpecifications:1) Power supply: 380V 60Hz 2) Three-phase, four-wire 3) Cutting motor power: 3kW (1.5kW x 2)4) Cutting motor rotational speed: 3,300rpm5) Operation air pressure: 0.5 - 0.8MPa6) Air consumption: 30L/min7) Max. cutting length: 5,000mm8) Min. cutting length: 430mm 9) Cutting range (width x height): a) 230 x 90mm b) 20 x 105mm10) Cutting angle: 45 and 90 degrees11) Cutter feeding speed: 0 - 3 m/min (step-less speed regulating) 12) Saw blade specifications: φ457 x 4 x φ25.4Inner packing:Plastic cover, nylon coverOuter packing:Wooden caseCarton dimensions (L x W x H): 4,900 x 1,800 x 2,000mmN.W.: 1,200kgG.W.: 1,350kg
