capacity 30mm jack screw,screw jack lift table dwg,meter gear machine jacks
capacity 30mm jack screw,screw jack lift table dwg,meter gear machine jacks features:1. Maximum load capacity from 2.5 ton to 120 ton, maximum torque from 18 Nm to 3315 Nm.2. Lift screw diameter 30 mm to 180 mm, screw pitch 6 mm to 25 mm.3. Each jack has two gear ratio from 1/6 to 1/36.4. Translating screw, rotating screw, keyed screw configurations in upright or inverted mounting orientation.5. Precisely positioning, self-locking acme screw which supports the loads and hold position with no need to employ brake mechanism or other locking systems.6. Manual screw jack by hand wheel or hand crank, motor screw jack by electric motor or gearmotor driven, or both.7. 3-phase or single phase motor driven with 1500 rpm input, standard lifting speed 1500 mm/min and 375 mm/min. 8. No standard lift screw stroke, maximum travel stroke 1500mm to 7000mm when tension load. 9. Top plate, clevis end, plain end and threaded end are available.10. Individually or multiple worm gear screw jacks lifting system are available.11. Application in steel, pipe, tube, plate, roll forming roller adjustment, feeder straightener rolls adjustment, adjusting synchronous coil feed lines rolls, precision roller leveler, coil sheet slitter line, paint coating line, cut to length line, tension levelling line, continuous galvanizing line, beverage production line, foam concrete cutting machine, sanding machine, heavy vehicles mobile lifting platform, bottle monitoring system height adjustment, conveyor adjustment, plate saw angle adjustment, spray infeed conveyor lift system, theatre stage lifting platform, solar tracker, satellite dish antenna azimuth, raising sluice gate, screw scissor lift table, synchronized lifting system, food processing lifting system, extrusion machine, cnc steel leveling machine, blow molding machine, curing oven lifts, bolted tank, steel shuttering concrete beams adjustment, vintage industrial crank desk, solar panel tracking system, railway maintenance lifting jack, damper adjustment, continuous casting, cnc cut to length machine, robotics arm raising, palletizer, extrusion machine, motorized self-raising tower system, angle tilt adjustments with double clevis, aircraft docking system, open and close flood gates, metallurgy industry, mining industry, chemical industry, construction industry and irrigation industry.
compact acme screw jacks, mechanical gear jack, machine screw jack features:1. Load capacity 2.5KN, 0.5 ton, 1 ton, 2 ton, 2.5 ton, 3 ton, 5 ton, 10 ton, 15 ton, 20 ton, 25 ton, 30 ton, 35 ton, 40 ton
compact ball screw jack,ball screw jacks electric,manual ball screw jack features:1. Lifting force 5kN to 500kN. Under max. lifting force, input shaft required torque, high ratio 1.3Nm to 318Nm,
direction change gearbox, directions of the gearbox according to input and output features:1. Right angle assembly pairs spiral bevel gears.2. Used to transmit rotary motion, mechanical powe
electric screw lift system,heavy duty linear table,synchronized jack systems include bevel gearboxes, screw jacks, electric motor, gear reducer, hand wheel, pillow block bearing, jaw couplings an
gear driven jack, linear gear drive, gear jack, gear pinon screw jack features:1. Load capacity 2.5KN, 0.5 ton, 1 ton, 2 ton, 2.5 ton, 3 ton, 5 ton, 10 ton, 15 ton, 20 ton, 25 ton, 30 ton, 35 ton, 40
gear reducer 90,spiral 4 speed in 90 degree drive,1 to 1 ration gearbox features:1. 90 degree angle assembly spiral bevel gears.2. Used to transmit rotary motion, mechanical power and torque.3. M
