direction change gearbox, directions of the gearbox according to input and outpu
direction change gearbox, directions of the gearbox according to input and output features:1. Right angle assembly pairs spiral bevel gears.2. Used to transmit rotary motion, mechanical power and torque.3. Milled cubic body sizes 54x54x54mm to 280x280x280mm.4. High efficiency bevel gearbox, up to 98%.5. Gear ratios 1:1, 1.5:1, 2:1, 3:1, 4:1, 5:1, customized special gear ratio.6. Input power maximum 1.5Kw to 188Kw. Drive torque maximum 12N.m to 1299N.m. Input and output speed maximum 1500Rpm (high speed gearbox, contact Jacton engineers).7. 11mm to 60mm diameter input and output shaft, 8 types shaft arrangements and direction of shaft rotating. Shafts can be rotated in both forward and reverse direction. Clockwise and counter-clockwise rotation direction are available.8. Soild shaft, hollow shaft and motor flange adapter are available.9. horizontal mounting, overhung mounting or wall mounting are available.10. 2 way shaft gearbox, 3 way shaft gearbox, 4 way shaft gearbox are available.11. low backlash 8 to 15 arcmin, quiet low noise less than 80dB under 1500rpm at 1 meter distance, low working temperature less than 50 degree centigrade.12. application in printing press, plastic extruder, sewage auger, bonding equipment, metering auger, sewage agitator, newspaper conveyor, bottling equipment, material handling, web finishing, paper conveying, conveyor, cardboard box equipment, packaging, satellite dish antennas, gate valve actuators, food processing, robotics, rubber processing, wrapping machine, solar panel, commercial mower, street sweeper, dual steering, bulkhead door opener, scissor lift, vertical pump drive, sand spreader, residential mower, car wash curtain, snow blower, mining equipment, crane, agricultural, grain wagon, harvester, forage harvester, manure spreader, fertilizer spreader, business form press, feed screw drive, sewage conveyor, collating machinery, mixing equipment, conveyor drive, screw jack system, film processor and pottle packaging equipment. Whatever your goal is to blend, blow, bottle, crank, cut, convey or the task is to press, propel or raise, Jacton bevel gearbox is welcomed and ideal power transmission solution with all these industries.
electric screw lift system,heavy duty linear table,synchronized jack systems include bevel gearboxes, screw jacks, electric motor, gear reducer, hand wheel, pillow block bearing, jaw couplings an
gear driven jack, linear gear drive, gear jack, gear pinon screw jack features:1. Load capacity 2.5KN, 0.5 ton, 1 ton, 2 ton, 2.5 ton, 3 ton, 5 ton, 10 ton, 15 ton, 20 ton, 25 ton, 30 ton, 35 ton, 40
gear reducer 90,spiral 4 speed in 90 degree drive,1 to 1 ration gearbox features:1. 90 degree angle assembly spiral bevel gears.2. Used to transmit rotary motion, mechanical power and torque.3. M
gearbox 90 degree aluminium,gearbox ratio 1:1,200 hp gear box features:1. 90 degree angle assembly spiral bevel gears.2. Used to transmit rotary motion, mechanical power and torque.3. Milled cubi
