Информация о производителе
Компания:
Sharpvision Co., Ltd. |
| |
Адрес:
Factory Building 4/F, No. 4, Tangdong East Road, Tangdong Village, Tianhe, Guangzhou, Guangdong, China (Mainland) |
| |
Телефон:
+86-20-85572236 +85572237 +85545366 |
|
.
Specifications:1 / 4" B/W CMOS sensor:1) Without audio and IR2) Image device: OV51163) TV system: CCIR / EIA4) Effective pixels: 352 x 288 pixels / 320 x 240 pixels5) Sensing area: 3.2 x 2.5mm6) Scanning system: 2:1 interlace7) Sync. system: internal8) Resolutions: 240 TV lines9) Horizontal sync. frequency: 15.625kHz / 15.734kHz10) Vertical sync. frequency: 50Hz / 60Hz11) Minimum illumination: 0.5lux/F1.212) Video output: 1.0vp-p, 75 ohms13) Gamma consumption: 0.4514) AGC: auto15) S/N ratio: better than 46dB16) White balance: auto17) Electronic shutter: 1/50 - 1/6,000 seconds18) BLC: auto19) Current consumption: 50mA20) Power supply: DC12V21) Operating temperature: -10 - 45°C, RH95% max.22) Storage temperature: -30 - 60°C, RH95% max.23) Lens: f=3.6mm / F = 2.024) Lens angle: 69°1 / 3" color CMOS sensor:1) Without audio and IR2) Image device: OV79103) TV system: PAL / NTSC4) Effective pixels: 628 x 582 pixels / 510 x 492 pixels5) Sensing area: 5.78 x 4.19mm / 4.69 x 3.54mm6) Scanning system: 2:1 interlace7) Sync. system: internal8) Resolutions: 380 TV lines9) Horizontal sync. frequency: 15.625kHz / 15.734KHz10) Vertical sync. frequency: 50Hz / 60Hz11) Minimum illumination: 3lux/F1.212) Video output: 1.0vp-p, 75 ohms13) Gamma consumption: 0.4514) AGC: auto15) S/N ratio: better than 48dB16) White balance: auto17) Electronic shutter: 1/60 - 1/15,000 seconds18) BLC: auto19) Current consumption: 50mA20) Power supply: DC12V21) Operating temperature: -10 - 46°C, RH95% max.22) Storage temperature: -30 - 60°C, RH95% max.23) Lens: f=6.0mm / F = 2.024) Lens angle: 69°1 / 3" B/W CCD sensor:1) Without audio and IR2) Image device: Sharp3) TV system: CCIR / EIA4) Effective pixels: 512 x 582 pixels / 512 x 492 pixels5) Sensing area: 4.9 x 3.7mm6) Scanning system: 2:1interlace7) Sync. system: internal8) Resolutions: 420 TV lines9) Minimum illumination: 0.05lux / F 1.210) Horizontal sync. frequency: 15.625kHz / 15.734kHz11) Vertical sync. frequency: 50Hz / 60Hz12) Video output: 1.0vp-p, 75 ohms13) Gamma consumption: 0.4514) AGC: auto15) S/N ratio: better than 48dB16) White balance: auto17) Electronic shutter: 1/50(CCIR) / 1/60(EIA) ~ 1/10,000 seconds18) BLC: auto19) Current consumption: max. 110mA20) Power supply: DC12V21) Operating temperature: -20 - 70°C, RH95% max.22) Storage temperature: -40 - 85°C, RH95% max.23) Lens: f=3.6mm / F = 2.024) Lens angle: 92°1 / 4" color CCD sensor:1) Without audio and IR2) Image device: Sharp3) TV system: PAL / NTSC4) Effective pixels: 512 x 582 pixels / 512 x 492 pixels5) Sensing area: 3.6 x 2.7mm6) Scanning system: 2:1 interlace7) Sync. system: internal8) Resolution: 420 TV lines9) Minimum illumination: 1lux/F1.210) Horizontal sync. frequency: 15.625kHz / 15.734kHz11) Vertical sync. frequency: 50Hz / 60Hz12) Video output: 1.0vp-p, 75 ohms13) Gamma consumption: 0.4514) AGC: auto15) S/N ratio: better than 48dB16) White balance: auto17) Electronic shutter: 1/60(NTSC) / 1/50(PAL) ~ 1/10,000 seconds18) BLC: auto19) Current consumption: max. 100mA20) Power supply: DC12V21) Operating temperature: -20 - 70°C, RH95% max.22) Storage temperature: -40 - 85°C, RH95% max.23) Lens: f=3.6mm / F = 2.024) Lens angle: 69°
|
