Model: JZ-9306AMotor: 1/2HPStroke: 20-45mmRiveting capacity (mild steel): solid rivet: 3-1; hollow rivet: 1-25Working cycle time (sec): 0-6Ordinary pressure (kg/cm2²): 20-70Max. pressure (kg/cm&s

Model: JZ-9306CMotor: 3HPStroke: 20-45mmRiveting capacity (mild steel): solid rivet: 1-25; hollow rivet: 1-40Working cycle time (sec): 0-6Ordinary pressure (kg/cm2²): 20-100Max. pressure (kg/cm2&

Model: JZ-9306CMotor: 3HPStroke: 20-45mmRiveting capacity (mild steel): solid rivet: 1-25; hollow rivet: 1-40Working cycle time (sec): 0-6Ordinary pressure (kg/cm2²): 20-100Max. pressure (kg/cm2&

Model: JZ-9306AMotor: 1/2HPStroke: 20-45mmRiveting capacity (mild steel): solid rivet: 3-1; hollow rivet: 1-25Working cycle time (sec): 0-6Ordinary pressure (kg/cm2²): 20-70Max. pressure (kg/cm&s

We can supply hydraulic stamping and embossing machines.

Rivet diameter: 2.4-3.0mmRivet length: 3-8mmThroat depth: 80mmMotor: 1/4HPMachine dimensions (L x W x H): 550 x 1,000 x 1,430mmPacking:N.W.: 80kgG.W.: 130kg

Model: JZ-968MLRivet diameter: φ3-5mmRivet length: 5-20mmThroat depth: 250mmMotor: 3/4HPHeight from floor to bottom mold: 850mmMachine dimensions (L x W x H): 770 x 480 x 1,420mmPacking:N.W.: 240

Model: JZ-938Cutting length: 1-99,999mmCutting width: 1-160mmPower: 1/4HPVoltage: 110V/220VPacking:Packing dimensions (L x W x H): 600 x 700 x 1,000mmN.W.: 85kgG.W.: 120kg

Model: JZ-928Cutting length: 1-99,999mmCutting width: 1-100mmPower: 1/4HPVoltage: 110V/220VMeasurement: 500 x 450 x 450mmPacking:N.W.: 34kgG.W.: 50kg
