Copper Conductor Power Cable
Product Name: Copper Conductor Power CableModel Number: (LV CABLE)Place of Origin: China Conductor : Class 2 of compacted circular or circular stranded plain or tin-coatedcopper or aluminum Separator : Polyester tape may be applied between conductor and insulation. Insulation : Cross-linked polyethylene (XLPE) or flame retardant XLPE insulation Filler : Polypropylene yarn or compound Binder tape : Lapped tape Outer sheath : Extruded Polyvinyl Chloride (PVC), Polyethylene (PE), HDPE or PVC or LSZH outer sheath.FEATURES Maximum conductor temperature....Normal continuous : 90 C....Overload : 130 C....Short circuit : 250 C Excellent resistance to electrochemical treeing, corona, heat, moisture and a widevariety of industrialchemicals. PVC outer sheath provides mechanical protection of the insulation during installationas well asprotection from many industrial chemicals. Sunlight resistance for outdoor use.OPTIONS Conductor shape : Stranded circular or shaped (sector) conductor Insulation material : XLPE, FR-XLPE or EPR Flame retardant cables can be available by the special request. Water blocking cables can be available by the special request. REFERENCE STANDARDS:IEC 60228, 60502-1, 60811, BS 5467, 6346, 6360, 7655
Features:1) Circular copper conductor for single core and shaped conductors for multi-core,PVC insulated PVC bedding, unarmored or armored, PVC sheathed power cable2) Laid in buildings, tunnels or tre
Features:1) Solid or stranded copper conductor PVC insulated and PVC sheathed cables (twocores or three cores)2) Suitable for indoor or outdoor surface wiring3) 300/500V4) 227IEC-4 (BVVB)
As a result of stable intermolecular bonds, XLPE insulated cable has much betterthermal and mechanical properties than the conventional polyethylene. This propertymakes XLPE insulated cables used at m
Product Name: Copper Conductor XLPE insulated Power CableModel Number: MV cablePlace of Origin: ChinaAs a result of stable intermolecular bonds, XLPE insulated cable has much betterthermal and mechani
Product DescriptionPVC insulated wires belong to the series of laying electric wires, which are mainlysuitable for placing at the fixed places. It is widely used as connectors ofdrive, lighting, elect
