FTTH Triple Play Access Solution
Main Equipment:Optical line terminal(OLT): OnAccess2224D series managed triple play optical Ethernetswitch.24 100Base-BX10 ports, 24 CATV optical signal output ports, two 10/100/1000Base-TXor optional SFP 1000Base-X ports, one CATV optical signal input port.Optical network unit (ONU): OnAccessH1002D or OnAccessH1004D series triple playoptical network unit On AccessH1002D One 100Base-BX10 WAN port, One CATV optical signal input port, Four 10/100Base-TX LAN ports, One 75 coaxial-cable CATV port with RF bandwidth of 45~860MHz or 45-1000MHz.OnAccessH1004D One 100Base-BX10 WAN port, One CATV optical signal fiber input port, Four 10/100Base-TX LAN ports, Two POTS telephony (FXS) ports or one POTS (FXS) plus one PSTN telephony (FXO) ports, One 75 coaxial-cable CATV port with RF bandwidth of 45~860MHz or 45~1000MHz.Features:Dual fibers: one for data, another for CATVTriple play access solution: broadband data + CATV + IP/POTS phonesHigh bandwidth: 100Mbps full duplexWide CATV bandwidth: 45~860MHzTelephony options: IP phone or POTS phoneP2P topology: flexible, scalable and easy to manage, high reliability, high privacy.Long operation distance: up to 15 kmTx1310nm/Rx1310nm or Tx1310nm/Rx1550nm for duplex data, 1550nm or 1310nm for CATV(when 1310nm for CATV, 1310nm transmitter should replace EDFA )Centralized active node: all active switches installed in a remote officeLow equipment cost: less than USD400 per line
