Computer Controlled Vest Bag Sealing and Cutting Machine
Summary:The machine is not only used for bottom sealing and cutting roller material of laminating colour printed film after it has been processed on the middle-sealing machine or edge-sealing machine but also for cross-cutting plastic film and cardboard trademark. It adopts microcomputer photo control locating control, state digit display and length panel control and has such functions as automatic alarm on reaching the set value and counting protection on power off, so it has such characteristics as easy length setting, high locating accuracy, stable feeding, uniform tension, automatic temperature control stepless speed regulating, easy operation and stable performance.Main Technical Variables Model FM-GFQ-600, FM-GFQ-800, FM-GFQ-1000Max. Width of bag-making600mm, 800mm, 1000mmMax. Length of bag-making 950mm, 950mm, 1200mmSpeed of bag-making 30-130pcs/min, 30-130pcs/min, 30-130pcs/minPower of main motor 0.75kW, 1.5kW, 2.2kWWeight 750kg, 800kg, 900kgExternal dimension(LxWxH) 2900x1350x1650mm, 2900x1450x1550mm
