Protection Module
It has excess voltage and current protection function, also has overload to earthingfunction. We use the three electrodes gaseous discharge tube and high polymerPTC as the protection component. The whole performance meets the requirement ofKorea KT.Technical Performance:1) Insulation resistance: >1000M Ohm2) Bound of limited voltage: 180~300V3) Capability of bearing alternating current: 5A, duration 1s, 5 times, interval 3minonce4) Capability of bearing dash current: 100A; 10/1000us waveform, 300 times, interval3min once5) Fail-safed current: 250mA6) Over current action time:7) Unactivated current: 150mAMaterial Performance:1) Plastic Material: all the plastic parts use flame retardant material, the flameretardant capability reaches level FV-0;2) High-performance tin bronze, Cu+P+Sn>99.7%
Features:1) Contact resistance (body resistance not included):normal atmosphere2) Insulation resistance: ≥1,000M ohms under normal atmosphere3) Dielectric strength: DC 1,000V (AC 700V) (no break-do
It adopts the insulating displacement connection (IDC) technology.There is 45 degrees between reed and wire. The touch point between reedand reed can be cut when contact.The transmission performance f
