300/400cc 2WD/4WD ATV
Model: AP-ATV22Overall dimensions (L x W x H): 2,070 x 1, 150 x 1, 175mmGround clearance: 200mmMax. speed: over 90km/hClimbing ability: over 30 degreeSpecification of front wheel: 25/8-12 (38F)Specification of rear wheel: 25/10-12 (45F)Distance between front wheel: 860mmDistance between rear wheel: 860mmDistance between front and rear wheel: 600mmSeat height: 900mmDistance between front axle and rear axle: 1,235mmGross weight: 350kgDry weight: 300kgSystem front/rear brake: disk/diskEngine style: single cylinder, 4 stroke, Water cooledCylinder dia. working stroke: 71 x 71/78mmEfficient capacity: 284/367mlRated power and rotate speed: 15.2/17.2kW/7,600rpmMax. torque and rotate speed: 23/26N.m/6,000rpmCompressing ratio: 2.444-0.829Gearshift mode: CVT/reverseTransmission: 4 drives/shaft drive, manual front driveStarting system: electricCooling system: water- cooledFuel tank: 13LPacking dimensions: 1,950 x 1,150 x 860mmConveyance:Qty/20` FCL: 12pcsQty/40` FCL: 36pcs
Dimensions (L x W x H): 1,900 x 1,050 x 1,150mmMax. speed: 60km/hEngine type: 4-stroke, 1 cylinder, oil-cooledBore x stroke: 78 x 61.2mmEfficient capacity: 292.4mlRated power and rotate speed: 14.7kW/
