15 – 36kV Outdoor Cutout
Types:1) According to voltage: 15, 27 and 36kV outdoor cutouts2) According to structure: SS1, SS2 and SS3 outdoor cutoutsa) SS1 15-36kV outdoor cutouts (without arcing flat)b) SS2 15-36kV outdoor cutouts (with pothook)c) SS3 15-36kV outdoor cutouts (with arcing flat)Application conditions:1) Ambient temperature: -40~+55°C2) No more than 1,000m altitude3) No more than 34m/s wind speed4) Suitable for IV degree of contaminationProduct type: ① ② - ③/④ - ⑤①: SS seven star series of outdoor falling fuses②: Without the arching flat, with the pothook, with the pothook③ Rated current: 1=100A, 2=200A④ Rated voltage⑤ Fuse currentProduct features:1) Combine with HUBELL`s fuses link and provide transformers, capacitors, cables and circuits with complete fault protection2) Outstanding capacity to interrupt the fault 12.5kA/15kV and 16kA/15kV3) Adapt the principle of arching with gases expelled gradually at both ends, design specially pressure release cap (vent), apply button head type link and sheaths fuse with assistant arcing tube4) Apply solid cast copper material to ensure the reliability of on/off, apply the new materials for fuse and inorganic materials for arching5) Maintenance free, ultraviolet radiation resistantOthers:1) Strictly tested2) Size of fuses:a) Fuse current: 5, 10, 15, 20, 25, 30, 35, 40, 45, 50, 60, 80, 100, 125, 160, 200Ab) Rated voltage: 15, 27, 36kV3) Application: suitable for application in the heavy contaminated environment and the area of high temperature and moisturePacking:Paper carton dimension and gross weight:1) SS1 and SS2:500 x 340 x 110mm, 7.5kg2) SS3:570 x 370 x 140mm, 8.5kg
