Butterfly Valve (Pneumatic Actuator/Electric Actuator)
JP-830 / JP-840 Butterfly Valve (Pneumatic Actuator / Electric Actuator ^ Marerial GUPVC. PP. CPVC. PVDF. EPDM. FPM. Size G2``~ 12`` @ Standard G10K A150# ADIN End Type GFlanged *Pressure rating : 2``~10`` 150 PSI, 12``~14`` 100 PSI, 16`` 86 PSI (Pneumatic Actuator / Electric Actuator) 18`` 72 PSI, 20``~24`` 51 PSI (Pneumatic Actuator) *Low flow loss **Pneumatic Actuator : The opening angle of the disc could be seen clearly throung the position indicator. Fast / Efficient operation for automatic control system in a limited piping space. Pneumatic actuator specification meets with ISO 5211, VDI / VDE 3845,DIN 3337. Pneumatic catuator Max.inlet pressure 8kg/cm² , Min.air pressure 4kg/cm² , **Electric Actuator : Electric actuator operation voltage 1-phase 110/220V, 3-phase 220/380/460V. Electric actuator could manually operate w/o clutch and break.
