JMY980 series, based on NXP PCD, are the USB PC/SC interface smart reader. The reader supports series IC cards according to ISO14443A, ISO14443B, ISO15693 and ISO7816; various contactless IC card under international standard. There are 2 SAM card slots in the reader which support SAM cards compliant with ISO7816 (T=0 and T=1). The reader supports card-reset of various communication rate; PPSS operation after card-reset; SAM operation of various communication rate and also the powerful PC operating software --TransWin & freed SDK & example: VC, BC, VB, DELPHI etc. Qualifications: • PCD: MF RC531; CL RC632• Working frequency: 13.56MHz• RF standard: ISO14443A, ISO14443B, ISO15693• Operating distance: 100mm (Mifare One, typical distance)• SAM card slot: 2 slots (supported ISO7816 T=0 and T=1)• Interface: USB PC/SC• Power supply: DC5V • Power consumption: 300mA• Dimension: 123mm × 88mm × 25mm• Weight: about 100g • Operating temperature: -25 ~ +85 ℃ (-77 ~ +185°F)• Storage temperature: -40 ~ +125 ℃ (-104 ~ +257°F)
JMY609, based on NXP PCD, is the reader module. The module supports series IC cards according to ISO14443A, ISO14443B and imitates the USB keyboard to read and output the card data. JMY609 is reade
JMY622 series are 13.56MHz RFID reader/writer module with UART and IIC serial ports. The module would meet EMV2000, EMV2010 and PBOC 2.0 standards. And the module and antenna is linked by 50
JMY501 series are RFID reader/writer module with UART and IIC serial ports. JMY501 has various functions and supports multi ISO/IEC standard of contactless card; the cards from d
JMY680 series are RFID reader/writer module with IIC or UART serial ports. JMY680 has various functions and supports multi ISO/IEC standard of contactless IC card; the cards from different supplier
JMY612 series are RFID reader/writer module with RS232C serial ports. JMY612 has various functions and supports multi ISO/IEC standard of contactless card; the cards from different suppliers.
JMY607 series are RFID reader/writer module with IIC or UART serial ports. JMY607 has various functions and supports multi ISO/IEC standard of contactless IC card; the
MR730 series contactless smart reader is the Ethernet interface desktop reader based on NXP PCD or compatible PCD. It doesn't have display. The reader supports series IC cards acco
MR701 series, based on NXP PCD or compatible PCD, is popular and high performance desktop reader. The reader supports series IC cards according to ISO14443, ISO15693; various contactless IC c
MR761 series, based on NXP PCD, is the desktop reader. The reader supports series IC cards according to ISO14443A, ISO14443B and outputs the data by the way of simulation keyboard through USB inter
