1/3-inch Sony Super HAD CCD Box Camera with 0.05 Lux Low Light 420 TVL, 12V DC
System: NTSC/PAL
Pick-up device: 1/3-inch Sony Inter-line Transfer Super HAD CCD
Active picture elements (H x V):
NTSC: 510 x 492/PAL: 500 x 582
Synchronization system: internal/line lock (dip switch adjust)
Gamma correct: 0.45
Minimum illumination: 0.1 Lux F 1.2
Horizontal resolution: 420TVL (color)
White balance: auto trace white balance (2,500 to 9,500K)
Electric shutter:
Auto: NTSC: 1/60 to 1/10ks; PAL: 1/50 to 100ks
S/N ratio: more than 48dB (AGC off)
Auto Gain Control (AGC): super AGC/normal AGC (dip switch adjust)
Line lock: on/off (dip switch adjust)
Backlight compensation (BLC): on/off (dip switch adjust)
Video output: BNC composite: 1.0 Vp-p/75 Ohms
Lens mount: C/CS mount
External adjustment: DC-iris level control
Internal adjustment:
Electronic shutter ON/OFF, BLC: ON/OFF
AGC: super/normal, flickerless; on /off; soft/sharp adjust
External connection: DC-iris (four-pin), video (BNC), DC 12V input
Camera mount: mounting socket on bottom or top
Current: 200mA (maximum) DC 12V
Power supply: DC 12V/DC 12V/AC 24V (EL-C216-W), AC 90 to 230V (EL-C214-W)
Power consumptiom: 2.4W maximum
Operation temperature: -10 to +50 degrees C
Dimension: refer to drawing
Color: silver gray
Options:
EL-C224: AC 90 to 230V
EL-C225: dual voltage DC 12V/AC 24V
EL-C226R: day/night with IR filter
1/3-inch Sony super HAD CCD sensor
Built-in 24 IR LEDs 15M projection distance
No reflection from IR light
Panning up to 360 degrees
Built-in 6mm lens (interchangeable lens: 4.3 to 12mm)
Res
1/3" Sony Super HAD CCD Sensor
Equipped with Extremely High Sensitivity CCD Seneor
Removable IR Cut Filter Enables it a Real Day/Night Camera
Easy Back Focus Adjustment
Ideal Multi-Purpose Surveil
1/3-inch Sony super HAD CCD sensor
Built-in 36 LEDs for 30m projection distance
Resolution: 540TVL
Minimum illumination: 0.1 to 0 lux (IR on)
Weather-resistant IP66
6mm lens (interchangeable
1/3-inch Sony super HAD CCD sensor
Build-in 4.0mm F 1.1 aspherical lens
420TVL (color)
Deliver clear and crisp color image in low lux environment
0.003lLux
Weatherproof IP66
Ideal surveill
1/3-inch Sony super HAD CCD
Built-in 20 pieces high light LED
Projection distance: 50m
Projection angel: 65 degrees
Resolution: 420TVL (color)
Lens: 9 to 22mm, or optional 3.5 to 12mm and 4
1/4-inch inter-line transfer CCD sensor Build-in 36 LEDs for 30M projection distance Resolution: 380TVL 0.1 to 0 Lux (IR On) Weather-resistant IP 66 6mm lens (interchangeable lens up to 25mm) Voltage:
Features 1/4 Sony Super HAD CCD Sensor 220x Zoom( 22x Optical Zoom, 10x Digital Zoom) 520 TV Line Motorised IR Filter for True Day/Night Function Power 12V DC/24V AC Auto Focus RS-485 (Pelco D, Pelco
36x optical zoom and 10x digital zoom
Day/night function with removable IR filter
Built-in multi-protocol
Continuous 360 Degree Pan
1/4-inch Sony Exview HAD CCD sensor
Four groups 64 preset
1/4-inch color CCD camera Greater than 250.000 pixel Horizontal resolution at 380TVL Internal sync system S/N ratio is more than 48dB Auto gain control Minimum illumination is 0.5Lux at F 2.0 Water-re
