XZJ5140JSQ Truck with Crane
1) Vehicle model: XZJ5140JSQ truck with crane2) Chassis model: EQ1141G7DJ23) Overall dimensions: 8,530 x 2,470 x 3,525/3,405/3,375/3,325/3,125mm4) Fact cubage: 10,000-12,000L5) Mass in working order: approx. 8,450, 8,350, 8,250, 7,900kg6) Body internal dimensions: 5,100/5,320 x 2,294 x 550mm7) Wheelbase: 5,000mm8) F/R track base: 1,940/1,860mm9) Approach/departure angle: 22/19°10) Exhaust/hp: 5,880ml/132kW11) Max. speed: 90km/h12) Tire specification: 10.00-2013) Engine type: EQB180-2014) Traction system: 4 x 215) Transmission: 6 speeds with over drive16) Number of axles: 217) Electric system: 24V18) Allowable passengers in cab: 319) Equipment:a) Crane`s lifting capacity options: 6.3, 5, 4 or 3.2MTb) Hydraulic valve is universal in the world on the safe side, three-point floating type to protect crossbeam of the truck, all hydraulic pressure, 360° turning, new H-shape type, high precise drawn tube, 24° tie-in20) Engine: Dongfeng Cummins environmentally friendly supercharge diesel engine (Europe II)21) Warranty: 12 months, from the date of supply
1) Vehicle model: XZJ5200JSQ truck with crane2) Chassis model: EQ1208GJ53) Overall dimensions: 9,630 x 2,470 x 3,780/3,770/3,610mm4) Fact cubage: 16,000-18,000L5) Mass in working order: approx. 13,700
1) Vehicle model: XZJ5200JSQ truck with crane2) Chassis model: EQ1208GJ53) Overall dimensions: 9,630 x 2,470 x 3,780/3,770/3,610mm4) Fact cubage: 16,000-18,000L5) Mass in working order: approx. 13,700
1) Vehicle model: CLW5040GJY fuel tanker2) Chassis model: EQ1032T51DJ33) Overall dimensions: 5,995 x 2,000 x 2,300mm4) Fact cubage: 4,000L5) Mass in working order: approx. 2,420kg6) Body internal dime
1) Vehicle model: CLW5040GJY fuel tanker2) Chassis model: EQ1032T51DJ33) Overall dimensions: 5,995 x 2,000 x 2,300mm4) Fact cubage: 4,000L5) Mass in working order: approx. 2,420kg6) Body internal dime
1) Vehicle model: CLW5040JSQ truck with crane2) Chassis model: EQ1032T51DJ33) Overall dimensions: 5,995 x 1,980 x 2,670mm4) Fact cubage: 2,300L5) Mass in working order: approx. 2,420kg6) Body internal
1) Vehicle model: CLW5040JSQ truck with crane2) Chassis model: EQ1032T51DJ33) Overall dimensions: 5,995 x 1,980 x 2,670mm4) Fact cubage: 2,300L5) Mass in working order: approx. 2,420kg6) Body internal
1) Vehicle model: CLW5050GXW fecal suction truck2) Chassis model: EQ1061T14DJ2A3) Overall dimensions: 5,600 x 1,890 x 2,340mm4) Fact cubage: 3,000-3,500L5) Mass in working order: approx. 3,725kg6) Bod
