Sterilizing Device
Product Name: Sterilizing DevicePlace of Origin: ChinaTechnical requirements:1) Except the grinding board, the surface of stainless steel parts is polished andwill not scratch2) Welding seam on external surface (except bottom welding seam) is grindedand polished, and other welding seams can be polished after acid cleaning3) Before assembly, the surface of each part is cleaned. The frame is injectedwith water through the top water sealing slot, and the bottom base bolts areadjusted to calibrate the level4) Error of horizontality of net bracket shall be less than 0.5/1,000, and thedeviation of diagonal line of the head wheel spindle and end wheel spindle shallbe less than 1.5mm5) Transportation belt entering into and going out of the tank have A, B, C, D beltsthat are determined according to the production taskTechnical parameters:1) Max. sterilizing temperature: 95°C2) Sterilizing mesh belt width: 1,500mm3) Sterilizing length: 4,000mm4) Pre-cooling length: 1,000mm5) Cooling length: 4,000mm6) Conveying speed: 0.11 – 0.51m/min7) Hot water cycle flow: 15m3/h8) Warm water cycle flow: 15m3/h9) Steam pressure: 0.4MPa10) Power: 7.47kW
