Description
MMDS Antenna Product Name: MMDS AntennaModel Number: WB-2Place of Origin: ChinaFeatures:1) Integrated gain: 50dB 2) RF input frequency: 2,500 - 2,686MHz3) RF output frequency: 222 - 408MHz (662MHz - 848MHz) 4) LO frequency: 2,278MHz±15kHz (1,838MHz) 5) LO frequency stability: ±30kHz; ±50kHz max. 6) Noise figure: 1.7dB 7) Gain: 32±2dB 8) Gain flatness: ±1.5dB, ±0.25dB/6MHz 9) Phase noise: -85dBc/Hz, 10kHz 10) Image rejection: 45dB 11) In band output spurious / harmonics: -50dBc 12) IF rejection: -75dB 13) PCS rejection: 100dB14) Third order intercept point: 24dBm 15) RF output level (max.) 16) With 31 channels each: 33dBmV 17) Output connector: F-Type, 75ohm 18) Supply voltage: +16 - +24V DC 19) Current: 225mA 20) Operating temperature: -40 - +80°C 21) Finish polyurethane powder coat paint 22) Physical size: 5.2 x 5.2 x 2.7"23) Yagi director length: 21.5" 24) Physical weight: 20oz. 25) Antenna: with yagi director 26) Gain: 17dBi 27) Front-to-back ratio: 18dB 28) Side lobe level: -12 29) 3dB beamwidth: 24 30) Cross polarization: -20dB 31) WCS rejection: 50dBc 32) IMD: -50dBc 33) For receiving more channels from microwave stations Outer packing:Dimensions: 61 x 45 x 39cm Add to Basket
Web address
Other goods of this manufacturer :
MMDS Down Converter
Product Name: MMDS Down ConverterModel Number: WB-4Place of Origin: ChinaSpecifications:1) Material: steel2) Gain: 38±2dB3) Noise figure: ≤ 2dB4) PF input frequency: 2,500-2,686MHz 5) IF out
MMDS Down Converter,WB-4
Product Name: MMDS Down Converter Model Number: WB-4Place of Origin: China Brand Name: HuashenMinimum Order: 2,000pcs Payment Terms: T/T, L/CDelivery Lead Time: 20 days Supply Ability: 50,000pcs/month
MMDS Integrated , A/D-2
Product Name: MMDS Integrated Down Converter Model Number: A/D-2Place of Origin: China Brand Name: HuashenMinimum Order: 2,000pcs Payment Terms: T/T, L/CDelivery Lead Time: 20 days Supply Ability: 50,
MMDS TV Antenna
Product Name: MMDS Antenna Model Number: WB-2Place of Origin: China Brand Name: HuashenQuality/Safety Certifications: ISO9001, CE Minimum Order: 1,000pcsPayment Terms: T/T, L/C Delivery Lead Time: 20
Outdoor TV Antenna (Digital)
Product Name: Outdoor TV Antenna (Digital)Model Number: A-02Place of Origin: ChinaSpecifications:1) Material: aluminum2) Gain: 8.5-19dB3) Input frequency: 48 - 960MHz4) Output impedance: 75 ohm
UVF Outdoor Antenna
Specifications:1) Material: aluminum2) Gain: 8.5-19dB3) Input frequency: 48 - 960MHz4) Output impedance: 75 ohms
Antenna
Freqency:45-860mhzGain:28-36dbPower:1.5w
C-Band LNBF Satellite
Specifications:1) Input frequency range: 3.4~4.2GHz2) Output frequency range: 950~1,750MHz3) L.o. frequency: 5,150MHz ± 1MHz4) L.o. frequency stability: 5,150/5,750MHz (max.) at -40~+60°C5)
